제품정보
주요기능 및 특장점
제품사양
| Model | 221 | 331 | 441 | 3351 | |
| Axis | 3 Axis | 3 Axis | 3 Axis | 4 Axis | |
| stroke(mm) | X1 axis | 200 | 300 | 400 | 300 |
| X2 axis (R axis) | - ( - ) | - (320°) | - (320°) | 300 | |
| Y axis | 200 | 300 | 400 | 500 | |
| Z axis | 50 | 100 | 100 | 100 | |
| servo motor(W) | X1 axis | 56 *42mm | 56 *76mm | 56 *76mm | 56 *76mm |
| X2 axis (R axis) | - () | - (56*76mm) | - (56*76mm) | 56 *76mm | |
| Y axis | 56 *76mm | 56 *76mm | 56 *76mm | 56 *76mm | |
| Z axis | 56 *76mm | 56 *76mm | 56 *76mm | 56 *76mm | |
| MAX.Load(kg) | X1 axis | 10kg | 10kg | 10kg | 10kg |
| X2 axis (R axis) | - | - (3kg) | - (3kg) | 10kg | |
| Y axis | 15kg | 15kg | 15kg | 15kg | |
| Z axis | 5kg | 5kg | 5kg | 5kg | |
| MAX.speed | X1 axis | 450mm/sec | 450mm/sec | 450mm/sec | 450mm/sec |
| X2 axis (R axis) | - ( ) | - (360°/s) | - (360°/s) | 450mm/sec | |
| Y axis | 450mm/sec | 450mm/sec | 450mm/sec | 450mm/sec | |
| Z axis | 200mm/sec | 200mm/sec | 200mm/sec | 200mm/sec | |
| Repeatability | ± 0.1mm | ± 0.1mm | ± 0.1mm | ± 0.1mm | |
| controller | inside | inside | inside | inside | |
