제품정보
주요기능 및 특장점
제품사양
| Model | 331 | 441 | 3351 | 4461 | |
| Axis | 3 Axis | 3 Axis | 4 Axis | 4 Axis | |
| stroke(mm) | X1 axis | 300 | 400 | 300 | 400 |
| X2 axis (R axis) | - (320°) | - (320°) | 300 | 400 | |
| Y axis | 300 | 400 | 500 | 600 | |
| Z axis | 100 | 100 | 100 | 100 | |
| servo motor(W) | X1 axis | 100 | 100 | 100 | 100 |
| X2 axis (R axis) | - (100) | - (100) | 100 | 100 | |
| Y axis | 100 | 100 | 200 | 200 | |
| Z axis | 100(Brake) | 100(Brake) | 100(Brake) | 100(Brake) | |
| MAX.Load(kg) | X1 axis | 24kg | 24kg | 24kg | 24kg |
| X2 axis (R axis) | - (3kg) | - (3kg) | 24kg | 24kg | |
| Y axis | 24kg | 24kg | 24kg | 24kg | |
| Z axis | 7kg | 7kg | 7kg | 7kg | |
| MAX.speed | X1 axis | 500mm/sec | 500mm/sec | 500mm/sec | 500mm/sec |
| X2 axis (R axis) | - (360°/s) | - (360°/s) | 500mm/sec | 500mm/sec | |
| Y axis | 500mm/sec | 500mm/sec | 500mm/sec | 500mm/sec | |
| Z axis | 500mm/sec | 500mm/sec | 500mm/sec | 500mm/sec | |
| Repeatability | ± 0.02mm | ± 0.02mm | ± 0.02mm | ± 0.02mm | |
| controller | inside | inside | inside | inside | |
재품도면도
