제품정보
주요기능 및 특장점
제품사양
| Model | BPP-050 | BPP-100 | BPP-500 | BPP-1000 |
| Dispensing Volume(60rpm/sec) | ≒0.05ml | ≒0.1ml | ≒0.5ml | ≒1ml |
| Motor Speed | 1~120rpm | 1~120rpm | 1~120rpm | 1~120rpm |
| Accuracy | ±1% | ±1% | ±1% | ±1% |
| Input Air Pressure | 0~6kgf/cm² | 0~6kgf/cm² | 0~6kgf/cm² | 0~6kgf/cm² |
| Material of Stator | FFKM | FFKM | FFKM | FFKM |
| Material of Motor | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| Inlet Port | G 1/4"(STD) | G 1/4"(STD) | G 1/4"(STD) | G 1/4"(STD) |
| Outlet Port | Luer Lock | Luer Lock | Luer Lock | Luer Lock |
| Wetting Part Material | SUS / UHMW-PE | SUS / UHMW-PE | SUS / UHMW-PE | SUS / UHMW-PE |
| Weight | 540g | 1.6kg | 540g | 1.6kg |
| Operating Condition | 10~40°C | 10~40°C | 10~40°C | 10~40°C |
제품도면도
