PCP-20-55 High-Viscosity Liquid Pressurized Pump
Main functions and benefits
The PCP-20-55 is a big high-viscosity liquid transfer pump engineered for transferring dense fluids directly from 20kg cans. This pump utilizes a pneumatic pressure system with a 55:1 pump sending ratio, making it ideal for applications requiring efficient handling of high-viscosity materials.
Key Features
- High-Viscosity Fluid Compatibility: Effectively handles fluids ranging from 50,000cps to 1,000,000cps, ensuring versatility across various industries.
- Efficient Pneumatic Pressure System: Transfers material smoothly and consistently, reducing waste and maintaining precision.
- Direct Can Usage: Operates directly from 20kg cans, eliminating the need for additional containers and minimizing material loss.
- Durable and Reliable Design: Built to withstand the demands of high-viscosity material transfer, ensuring long-term performance.
- Wide Application Range: Perfect for industries such as automotive, construction, and manufacturing that require precision fluid transfer for sealing, bonding, and molding processes.
Product specifications
| Model | PCP-20-55 |
| Pump Sending Ratio | 55:1 |
| Delivery | 10L/Min |
| Air Pressure | 3~7bar |
| Cycle Per Liter | 263 Cycle/L |
| Max. Working Pressure | 385bar |
| Max. Pump Speed | 60Cycle/Min |
| Air Motor Dia | 161mm |
| Stroke | 90mm |
