BV-3893 Needle-Off Valve is the large capacity version of the BV-386, designed to handle high viscosity fluids with even greater volume and precision. Operating on the same reliable needle-off mechanism, the BV-3893 is built for high-performance applications that require high-pressure dispensing of thick fluids, ranging from 1cps to paste consistency. Ideal for large-scale operations, this valve ensures accurate, efficient, and uninterrupted dispensing of high-viscosity materials.

• Large Capacity Dispensing: Capable of handling larger volumes of high-viscosity fluids, making it perfect for bulk applications and high-throughput production lines.
• Needle-Off Mechanism: The innovative needle-shaped pin ensures smooth, clean dispensing, preventing clumping and material buildup at the outlet.
• High-Pressure Performance: Designed to perform under high-pressure conditions, making it ideal for industries that require precision dispensing of thick pastes, adhesives, sealants, and more.
• Built for High Viscosity Fluids: Perfect for fluids with viscosities ranging from 1cps to paste, including thick adhesives, sealants, and lubricants.

Model	Needle Off
ON/OFF Method	BV-3893
Applicable viscosity	1~1,000,000cps
Input Air Pressure	5kgf/cm2
Max. fluid IN-LET pressure	210kgf/cm2
Max. operation number	240times/min
IN-LET Fittings	PT 1/4”
Wet-part material	SUS 303
Valve material	AL 6061
Weight	820g
