The TAD-200S is a single action precision controller engineered for advanced fluid dispensing applications. Designed for compatibility with barrels, cartridges, and single action valves, this controller enhances user convenience with features like interval timers, vacuum control, digital timers, and a memory function that retains dispensing settings even after power cycles. Developed with a Micro-Processor method, the TAD-200S ensures precise, consistent control for applications requiring minimal discharge volumes and quick, accurate dispensing, making it ideal for industries such as electronics, medical devices, and precision manufacturing.

• Interval Timer: Enables automatic dispensing and stop functions, allowing precise timing for consistent, repeatable cycles.
• Vacuum Control: Prevents drips from low-viscosity fluids by applying vacuum after each dispense, ensuring clean and accurate fluid control.
• Digital Timer: An LED display in manual mode makes it easy to monitor and adjust dispensing time settings in real-time.
• Memory Function: Retains previous dispensing settings, saving time and simplifying operations upon restart.
• External Output Options: Diverse output functions facilitate integration into automated workflows and interfaces for streamlined production.

Control Method	Electronic / Pneumatic System
Dispensing pressure	/  ㆍ 0~10kg/㎠ (S: Standard) /  ㆍ 0~4kg/㎠ (L: Option) /  ㆍ 0~2kg/㎠ (P: Option)
Time Range	0.01~99.99 sec
Interval Timer	0.01~99.99 sec
Vacuum Pressure	0~ -350mmHg
Out Signal	Open connector, DC 24V 20mmsec (Relay), 100mmsec (Relay)
Power Source	AC220C 50/60Hz (AC100V 50/60Hz: Option)
Power Consumption	32W
External Dimension & weight	232(W) x 186(D) x 81(H)mm, 2.7kg
