The TAD-200SP from Banseok is a specialized vacuum pick-up and dispensing controller that combines precision dispensing with a vacuum pick-up pen, making it an ideal tool for the assembly and reworking of small components. This integrated design allows you to transport components with a vacuum pad while simultaneously dispensing materials, streamlining assembly processes for tasks such as bonding lenses, glass, and other small parts.

• Dual Functionality: Combines both dispensing and vacuum pick-up capabilities in one device, enhancing efficiency in assembly and repair operations.
• Adjustable Vacuum Control: Allows for precise control of vacuum strength to suit the size and weight of various components.
• Versatile Vacuum Pad Options: Offers a wide selection of vacuum pad sizes, ranging from ∅2 to ∅32, to accommodate different component dimensions.
• Ideal for Precision Assembly: Perfect for applications requiring high accuracy, such as assembling lenses, glass, and small-sized parts in an assembly line.
• User-Friendly Operation: Equipped with the MN-5 pick-up pen for easy handling and reworking of components.

Model	TAD-200SP
Control Method	0.01~99.99 sec
Time Range	0.01~99.99 sec
Interval Timer	0.01~99.99 sec
Vacuum Pressure	0~ -350mmHg
Out Signal	Open connector, DC 24V 20mmsec(Relay
Power Source	AC220C 50/60Hz (AC100V 50/60Hz:Option)
Power Consumption	32W
External Dimension & weight	282(W) x 186(D) x 81(H)mm, 3.0kg
