PGP-20-10 system is a high-precision dispensing solution designed for high-viscosity liquids in 5-gallon pails (18.9271 litres). This system directly installs into the container, dispensing a fixed amount of fluid with high accuracy. It ensures the smooth discharge of thick materials without air bubbles or material loss. With a compact and lightweight design, the PGP-20-10 offers easy installation and optimal working conditions. Equipped with a self-developed simultaneous application valve, it enables precise dispensing to enhance productivity and quality. This pump operates without pulsation, providing consistent fluid flow for sealing, bonding, molding, and more.



• High-Viscosity Fluid Compatibility: Efficiently dispenses thick materials directly from a 5-gallon pail, eliminating air bubbles and material loss.
• Fixed-Amount Dispensing: Delivers precise, fixed quantities of fluid with every cycle for consistent results.
• Compact and Lightweight: Easy to install and operate in various working conditions for enhanced convenience.
• Self-Developed Application Valve: Provides precise, simultaneous application to improve both productivity and quality.
• Pulsation-Free Operation: Ensures smooth, consistent fluid flow without pulsation, improving dispensing accuracy.
• Versatile Applications: Suitable for sealing, bonding, molding, and other high-viscosity material applications.
• One-Pail Use: Recommended for use with a single 5-gallon pail for up to one month, ensuring efficient fluid management.

Model	PGP-20-10
cc/Rev	Customizing
Inlet Pressure	Max.2MPa(Max.20kgf/cm²)
Outlet Pressure	Max.5MPa(Max.50kgf/cm²)
Viscosity	10,000~400,000cps
Precision	±2%
Power Source	AC220C,50/60Hz
Material	Alloy Tool Steel, Stainless Steel, Aluminium
