BRGP-A Gear Pump system is designed for precise dispensing of high-viscosity fluid materials, using a 330ml cartridge. The fluid from the cartridge is directly transferred to the Gear Pump stage and supplied to the valve through the SERVO motor. This efficient system eliminates fluid loss and pulsation, ensuring smooth and accurate dispensing. Ideal for industries requiring consistent and reliable dispensing of high-viscosity materials without compromise.



• 330ml Cartridge System: Dispenses high-viscosity fluids directly from a 330ml cartridge for efficient and accurate dispensing.
• Pulsation-Free Operation: Eliminates pulsation for smooth, continuous fluid flow without loss of material.
• High-Viscosity Fluid Compatibility: Perfect for thick materials, ensuring consistent dispensing performance.
• SERVO Motor Powered: Utilizes a SERVO motor for precise control and superior repeatability in fluid dispensing.
• Direct Fluid Transfer: Transfers fluid from the cartridge directly to the Gear Pump stage for seamless operation.
• Minimal Fluid Loss: Designed to reduce waste, ensuring optimal use of fluid materials.

Model	BRGP
cc/Rev	Customizing
Inlet Pressure	Max.2MPa(Max.20kgf/cm²)
Outlet Pressure	Max.5MPa(Max.50kgf/cm²)
Viscosity	10,000~400,000cps
Precision	±2%
Power Source	AC220C,50/60Hz
Material	Alloy Tool Steel, Stainless Steel, Aluminium
